200T Cylinder Roof Tile Forming Machine Tile Manufacturing Machine

Brand Name : HHS

Model Number : XLB-550X550X4

Certification : CE/ISO

Place of Origin : CHINA

MOQ : 1 set

Price : USD:4000-20000 /SET

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100 sets/month

Packaging Details : wood package/20-40 gp

Heating Platen Size : 550X550

Mold Closing ForceF : 50T

Plate Clearance : 150mm

Working Layers : 4

Motor Power : 2.2KW

Overall Dimension : 2200X900X2200mm

Weight : 3600KG

Type : Vulcanizer,tile Machine

Color : blue,Customizable

Power source : Hydraulic

Usage : rubber tile from waste tyre granule, glue, colour

Keyword : high speed press machine

Contact Now

Rubber tile vulcanizing press is used to press the rubber tiles and rubber mats, it is good for using the recycling rubber.

200T Top Cylinder Rubber Tile Vulcanizing Press Machine / Roof Tile Forming Machine/ Tile Manufacturing Machine

1. Technical Parameters

No.	Model	XLB-550X550X4
1	Nominal Clamping Force	50T
2	Heating Platen Size	550X550mm
3	Tile Size	50X50cm,thickness 15-35-40 adjustable
4	Plate Clearance	150mm
5	Working Layers	4
6	Piston Stroke	400mm
7	Plate Unit Area Pressure	1.65Mpa
8	Motor Power	2.2KW
9	Overall Dimension	2200X900X2200mm
10	Weight	3600KG

2. Features

Manual push-pull mold

High output and efficiency

Easy and safe operating

3. The Detailed Introduction

1) we usually design as clients' products and details request. our machine is 4 working layers, 1 hour can made 8 pcs rubber floor. We can also according your needs. and decide the working layers.

2) the machine is matched with manual push-out device .

3) we also can provide the different size of the molds, from 20mm to 75mm thickness.

4) rubber mixer can also provided, if needed.

5) The press with 12 pcs molds and rubber mixer is only 8m³ of the flooring area, it can be LCL for loading, So the sea freight is very cheap.

6) We also can according to the customers' requirement, and design the non-standard type of rubber tile vulcanizing machine.

4. Detailed Pictures

200T Cylinder Roof Tile Forming Machine Tile Manufacturing Machine
